Wall mounted US plug 5V 9V 12V adapter

SPECIFICATIONS

Model: AD0181-xxx-yyyyZ

Input Voltage                     90〜264VAC

Input Frequency                47〜63Hz

Output Voltage Range       5v-32v
Output Current Range       100~3000mA

Output Power                     30W Max

Housing Size:                     78*61*28mm

Net Weight:                        80g

FEATURES:

LEVEL VI

Over current protection

Short circuit protection

RoHS compliant

ENVIRONMENT

Operation temperature            10℃to 40℃

Operation relative humidity      20% to 85%

Temperature Coefficient           0.05%/°C

Storage  humidity                     5% to 95%

CERTIFICATES:

CB CE GS ETL/UL FCC PSE SAA KC KCC RCM C-Tick

APPLICATION:

CCTV、DVR、Router、STB、Beauty devices、Vacuum Cleaner、Digital Camera、Speaker、Medical Equipment、POS machine etc
